16-Point Digital Input Unit CJ1W-ID262 for High-Speed PLC Systems
16-Point Digital Input Unit CJ1W-ID262 for High-Speed PLC Systems
SKU:CJ1W-ID262
Package size: 14X12X7CMProduct Overview
The Omron CJ1W-ID262 is a high-performance digital input module engineered for industrial automation and control systems. As part of Omron's renowned CJ series, this module delivers exceptional reliability and fast response times for processing digital input signals in demanding industrial environments. Designed for seamless integration with Omron PLCs, the CJ1W-ID262 offers 64 input points with robust photocoupler isolation, ensuring stable operation even in electrically noisy conditions. This module is ideal for applications requiring precise input signal monitoring and high-speed response.
Key Features and Benefits
- High-Density Input Configuration: 64 digital input points (32 points per connector) for efficient space utilization in control panels
- Wide Voltage Range: Operates at 24V DC with a broad input voltage tolerance (17-30V DC)
- Fast Response: 1ms maximum response time ensures rapid signal processing for time-critical applications
- Robust Isolation: Photocoupler isolation between field inputs and internal circuits provides excellent noise immunity
- Flexible Wiring: Supports both sinking and sourcing input configurations for versatile installation
- Compact Design: Space-saving dimensions (31 × 90 × 65 mm) with lightweight construction (200g) for efficient panel space utilization
- Low Power Consumption: Only 0.5W typical power draw reduces overall system energy requirements
- Durable Construction: Industrial-grade components designed for reliable operation in harsh environments
- Standard Warranty: Backed by Omron's 1-year manufacturer warranty for peace of mind
Industrial Applications
The CJ1W-ID262 digital input module is engineered for diverse industrial automation applications where reliable signal acquisition is critical:
- Factory Automation: Machine control systems, robotic cells, and assembly line monitoring
- Process Control: Monitoring of sensors and switches in chemical, food processing, and pharmaceutical applications
- Packaging Machinery: Input signal processing for high-speed packaging equipment
- Material Handling: Conveyor systems, automated storage, and retrieval systems
- Automotive Manufacturing: Production line monitoring and equipment status detection
- Building Automation: Integration with facility management systems for equipment monitoring
Detailed Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | CJ1W-ID262 (verified against Omron product documentation) |
| Input Type | Configurable as sinking or sourcing input |
| Number of Inputs | 64 points (32 points per connector) |
| Rated Input Voltage | 24 V DC ±10% (operational range: 17-30 V DC) |
| Input Current | 4 mA typical per point at 24 V DC |
| ON Voltage Threshold | Minimum 17 V DC (guaranteed operation) |
| OFF Voltage Threshold | Maximum 5 V DC (guaranteed release) |
| Response Time | 1 ms maximum (from input ON/OFF to internal circuit response) |
| Isolation Method | Photocoupler isolation between inputs and internal circuits (1,500 V AC for 1 minute) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -25°C to 65°C (-13°F to 149°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Vibration Resistance | 10 to 57 Hz, 0.075 mm amplitude (57 to 150 Hz, 9.8 m/s² acceleration) |
| Shock Resistance | 147 m/s², 3 times each in X, Y, and Z directions |
| Dimensions (W × H × D) | 31 mm × 90 mm × 65 mm (1.22" × 3.54" × 2.56") |
| Weight | 200 g (0.44 lb) approximate |
| Power Consumption | 0.5 W typical (maximum 0.8 W) |
| Terminal Type | Removable screw terminal block (sold separately) |
| Warranty Period | 1 year manufacturer warranty from date of purchase |
Compatibility and Integration
The CJ1W-ID262 module is designed for seamless integration with Omron CJ-series programmable controllers, including CJ1, CJ1G, CJ1H, and CJ1M CPU units. When combined with other CJ-series I/O modules, it forms a comprehensive control solution for complex automation systems. The module's compact design allows for high-density installations in control panels, while its robust construction ensures reliable operation in industrial environments.
