Compact CP1E-N30DT-D PLC with 18 I/O, Ethernet, and Built-in Analog

Comprehensive Product Overview

The Omron CP1E-N30DT-D represents a pinnacle of efficiency in compact programmable logic controller (PLC) technology, engineered specifically for industrial automation excellence. As part of Omron's acclaimed CP1E series, this high-performance PLC delivers precision control in space-constrained environments while maintaining robust industrial-grade reliability. Its optimized architecture integrates 30 I/O points with advanced processing capabilities, making it ideal for demanding automation applications requiring both DC and AC input compatibility. Designed with rigorous Japanese engineering standards, the CP1E-N30DT-D ensures operational continuity in challenging conditions while offering exceptional value for small-to-medium scale control systems seeking Omron's renowned quality assurance.

Advanced Technical Features

• Hybrid Digital Input System: 18-point versatile input configuration combining 12 DC inputs (24V, sink/source compatible) with 6 AC inputs (100-120V AC) for flexible sensor integration across diverse voltage environments.
• High-Capacity Transistor Outputs: 12-point transistor outputs with 0.5A sink current per point (collector voltage: 5-24V DC), engineered for rapid switching of solenoids, relays, and indicators.
• Space-Optimized Industrial Design: Ultra-compact 90mm × 90mm × 75mm (W×H×D) footprint with DIN-rail mounting compatibility, enabling deployment in control panels with severe spatial limitations.
• Industrial-Grade Power Management: 24V DC power supply (±10% tolerance) with low 15W maximum consumption and built-in surge protection for stable operation in electrically noisy environments.
• Extended Environmental Tolerance: Certified operational range of 0°C to 55°C (32°F to 131°F) with 10-90% non-condensing humidity tolerance and -25°C to 75°C (-13°F to 167°F) storage capability.
• Lightweight Structural Engineering: 400g aluminum-alloy housed unit with vibration resistance (10-57Hz, 0.075mm amplitude) and 10G shock durability for mechanical robustness.
• Integrated RS-232C Communication: Dedicated programming port supporting CX-Programmer software connectivity with 115.2kbps transfer speed for efficient project development and monitoring.
• Enhanced Memory Architecture: 4,000-step program memory capacity with 4KB data memory storage, supporting complex ladder logic with timer/counter functions and data processing.
• Omron Quality Assurance: Backed by comprehensive 1-year manufacturer warranty against defects in materials and workmanship, validating industrial reliability.

Industrial Application Solutions

The CP1E-N30DT-D provides versatile automation control across multiple industrial sectors with its hybrid input capability and compact form factor:

• Precision Manufacturing Systems: Central control unit for CNC machine tooling, precision assembly stations, and quality inspection systems requiring both AC proximity switches and DC photoelectric sensors.
• Material Handling Automation: Optimized for conveyor synchronization, automated sorting gates, palletizer sequencing, and robotic pick-and-place systems with high-speed counter functions.
• Packaging Machinery Control: Ideal solution for form-fill-seal equipment, labeling systems, and capping machines demanding precise timing control and output sequencing.
• Process Control Implementation: Manages small-scale batching operations, temperature control loops, and fluid handling processes with analog signal conditioning modules.
• Building Management Systems: Central controller for HVAC sequencing, lighting control panels, and energy monitoring systems in commercial facilities.
