NX1P2-1140DT Programmable Logic Controller with 40 I/O and Ethernet Port
NX1P2-1140DT Programmable Logic Controller with 40 I/O and Ethernet Port
SKU:NX1P2-1140DT
Package size: 21X17X15CMNX1P2-1140DT Programmable Logic Controller (PLC) - Industrial Automation Solution
The Omron NX1P2-1140DT is a high-performance programmable logic controller designed for demanding industrial automation applications. As part of Omron's renowned NX1P series, this compact yet powerful PLC combines a CPU, power supply, and integrated I/O units into a single robust housing, delivering exceptional control capabilities while optimizing installation space. Engineered for reliability and precision, this unit is ideal for applications requiring fast processing, flexible connectivity, and advanced automation features.
Key Features and Technical Advantages
- Comprehensive I/O Configuration: 24 digital inputs (sink/source compatible), 16 digital transistor outputs (0.5A per point), 4 analog inputs (0-10V/4-20mA), and 2 analog outputs (0-10V/4-20mA) for versatile signal handling.
- High-Speed Processing: Executes basic instructions in just 10 nanoseconds, ensuring rapid response times for critical automation tasks.
- Compact Industrial Design: Space-saving dimensions of 90 × 100 × 75 mm (W×H×D) with a lightweight 500g construction, suitable for panel mounting in space-constrained environments.
- Advanced Communication Capabilities: Integrated 100BASE-TX Ethernet port for network connectivity, plus RS-232C and USB ports for local programming and device communication.
- Robust Memory Capacity: 20 MB program memory and 64 KB data memory for complex automation programs and data logging requirements.
- Energy Efficient Operation: Low power consumption of 15W (typical) with a maximum of 20W, reducing operational costs.
- Industrial Durability: Operates reliably in temperatures from 0°C to 55°C with IP20 protection against particulate ingress.
- Standard Warranty: Backed by Omron's 1-year manufacturer warranty for peace of mind.
Industrial Applications
The NX1P2-1140DT is engineered for diverse automation challenges across multiple industries:
- Factory Automation: Ideal for machine control, sequential operations, and equipment monitoring in manufacturing environments.
- Packaging Systems: Provides precise timing control and synchronization for filling, labeling, and packaging machinery.
- Material Handling: Efficient control of conveyor systems, sorting equipment, and automated storage/retrieval systems.
- Process Industries: Suitable for batch processing, mixing, and quality control in food, beverage, and chemical applications.
- Building Management: Effective solution for HVAC control, lighting automation, and energy management systems.
Detailed Technical Specifications
| Parameter | Specification |
|---|---|
| Power Supply | 24V DC (±10% tolerance) |
| Digital Inputs | 24 points (sink/source configurable, 24V DC) |
| Digital Outputs | 16 points (transistor, 0.5A per point, 24V DC) |
| Analog Inputs | 4 channels (selectable 0-10V or 4-20mA) |
| Analog Outputs | 2 channels (selectable 0-10V or 4-20mA) |
| Processing Speed | 10ns per basic instruction |
| Communication Ports | Ethernet (100BASE-TX), RS-232C, USB |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -25°C to 75°C (-13°F to 167°F) |
| Humidity Range | 10% to 90% RH (non-condensing) |
| Vibration Resistance | 10-57Hz, 0.075mm amplitude; 57-150Hz, 9.8m/s² acceleration |
| Shock Resistance | 147m/s² (3 times each in X, Y, Z directions) |
| Protection Rating | IP20 (IEC 60529) |
| Mounting | DIN rail or panel mounting |
The Omron NX1P2-1140DT PLC represents an optimal balance of performance, compactness, and reliability for industrial automation systems. Its integrated design reduces wiring complexity while delivering the processing power needed for sophisticated control applications. With its comprehensive I/O capabilities and robust construction, this PLC is well-suited for OEM machine builders and system integrators looking for a cost-effective automation solution.
