10-inch V2 TFT Industrial HMI Touch Panel with High Brightness Display

Comprehensive Product Overview

The Omron NS5-TQ10B-V2 represents the pinnacle of industrial-grade programmable terminals within Omron's acclaimed Human-Machine Interface (HMI) series. Engineered for mission-critical automation environments, this advanced operator interface delivers robust monitoring and precision control capabilities for industrial machinery and process systems. Featuring a ruggedized IP65/NEMA 4X-rated front panel construction, the NS5-TQ10B-V2 withstands harsh operational conditions including dust ingress, high-pressure water jets, and extreme temperature fluctuations. Its intuitive touchscreen interface and versatile connectivity options enable seamless integration with PLCs, sensors, and industrial networks, optimizing operational visibility across automated systems.

Advanced Features and Operational Benefits

• High-Visibility Industrial Display: 5.7-inch TFT color LCD with 320 x 240 QVGA resolution and LED backlight technology ensures exceptional readability of process graphics, alarm statuses, and real-time data visualization under varying lighting conditions.
• Durable Touch Interface: 4-wire analog resistive touchscreen maintains consistent performance in demanding environments including exposure to vibrations, particulates, and operator glove use.
• Multi-Protocol Connectivity: Comprehensive communication interfaces including RS-232C (D-Sub 9-pin), RS-422/485 (terminal block), and USB Type B (programming port) ensure compatibility with Omron PLCs (CJ/CS/NJ series), third-party controllers, and Sysmac platform components.
• Rugged Industrial Construction: Compact 160 x 130 x 56 mm (6.3 x 5.1 x 2.2 in) die-cast aluminum enclosure with IP65-rated front protection guarantees reliable operation in washdown areas and particulate-heavy environments.
• Extended Environmental Tolerance: Certified operational range of 0°C to 50°C (32°F to 122°F) with non-operational storage capability from -20°C to 60°C (-4°F to 140°F), supporting deployment in unregulated industrial spaces.
• Energy-Efficient Power Architecture: 24 VDC (±10%) input with maximum 15W power consumption optimizes energy usage while maintaining compatibility with standard industrial power systems.
• Robust Vibration/Shock Resistance: Compliant with IEC 61131-2 standards for vibration (10-55Hz at 0.75mm amplitude) and shock resistance (147 m/s², 15G for 11ms), ensuring stability in high-impact manufacturing zones.
• Manufacturer Warranty: Backed by Omron's standard 1-year comprehensive warranty from date of purchase for assured reliability.

Industrial Application Scenarios

The NS5-TQ10B-V2 programmable terminal delivers exceptional performance across diverse automation environments:

• Automated Production Lines: Centralized monitoring and control interface for robotic assembly systems, CNC machinery, and conveyor operations with real-time diagnostics.
• Precision Process Control: Parameter adjustment and visualization for batch processing, chemical dosing, and thermal regulation systems in pharmaceutical and food processing industries.
• Predictive Maintenance Systems: Real-time display of equipment health metrics, vibration analysis, and failure alerts for rotational machinery in energy and heavy industry applications.
• Quality Assurance Stations: Operator interface for statistical process control (SPC) data visualization in automotive and electronics manufacturing test benches.
• Packaging and Material Handling: Configuration hub for fill-level monitoring, barcode verification, and throughput optimization in logistics automation.

Precision Technical Specifications

Parameter	Specification
Model Identifier	Omron NS5-TQ10B-V2 Programmable Terminal
Display Technology	5.7-inch Transmissive TFT Color LCD with LED Backlight
Native Resolution	320 (H) × 240 (V) pixels (QVGA Standard)
Touchscreen Technology	4-Wire Analog Resistive Touch Panel
Communication Interfaces	1 × RS-232C (D-Sub 9-pin male), 1 × RS-422/485 (Screw Terminal Block), 1 × USB 2.0 Type B (Peripheral Connection)
Physical Dimensions (W×H×D)	160 mm × 130 mm × 56 mm (6.30 × 5.12 × 2.20 in)
Panel Cutout Dimensions	152+0.50 mm × 122+0.50 mm (5.98 × 4.80 in)
Net Weight	600 g (1.32 lb) excluding mounting hardware
Power Supply Requirements	24 VDC ±10% (Ripple P-P: 10% max), Reverse Polarity Protection
Current Consumption	0.63 A typical (15.12 W) at 24 VDC
Ingress Protection Rating	IP65 Front Panel (NEMA 4X Equivalent)
Operating Temperature Range	0°C to 50°C (32°F to 122°F) with 10-90% RH non-condensing
Storage Temperature Range	-20°C to 60°C (-4°F to 140°F)
Vibration Endurance	10-55 Hz @ 0.75mm amplitude (3 axes, 2 hours per axis)
Shock Resistance	147 m/s² (15G) for 11ms duration (IEC 61131-2 compliant)
Warranty Coverage	1-Year Limited Manufacturer Warranty

System Integration and Compatibility

The NS5-TQ10B-V2 delivers native compatibility with Omron's industrial ecosystem while supporting multi-vendor integration:

• Direct integration with Omron CJ/CS/NJ series Programmable Logic Controllers via Sysmac Studio programming environment
• Seamless interoperability with Omron temperature controllers (E5CC/E5EC series), safety components, and IO-Link sensor networks
• Protocol support for Modbus RTU, Host Link communications, and standard ASCII interfaces for third-party PLC connectivity
• DIN-rail or panel mounting compatibility with VESA-standard industrial displays and control cabinets
