3G3AX-MX2-ECT Compact Inverter Drive with EMC Filter for Precision Motor Control

Product Overview

The 3G3AX-MX2-ECT is a high-performance communication expansion card from Omron's MX2 series, specifically engineered for seamless integration with compatible inverters. This modular expansion solution enhances industrial automation by enabling robust connectivity through RS-422/485 interfaces, supporting real-time control and monitoring of motor-driven systems. Designed for reliability in demanding environments, this expansion card is ideal for applications requiring precise motor control with serial communication capabilities.

Key Features

• Advanced Communication: RS-422/485 interface ensures stable data transmission in industrial environments with electrical noise.
• Compact Design: Space-saving dimensions (60 × 45 × 20 mm) allow flexible installation in control panels with limited space.
• Energy Efficient: Low power consumption (0.5 W typical) reduces operational costs without compromising performance.
• Rugged Construction: Operates reliably in temperatures from -10°C to +50°C and withstands vibrations up to 5.9 m/s² (10–55 Hz).
• Standard Compliance: Meets industrial-grade shock resistance (98 m/s²) and humidity resistance (20–90% non-condensing).
• Warranty: Backed by Omron's 1-year manufacturer warranty for guaranteed quality assurance.

Applications

• Industrial Motor Control: Precision speed and torque regulation for AC motors in manufacturing systems.
• Material Handling: Integration with conveyor belts, sorting systems, and automated guided vehicles (AGVs).
• HVAC & Fluid Control: Efficient management of pumps, fans, and compressors in building automation.
• Machinery Automation: Enables serial communication for PLC-controlled equipment like CNC machines and packaging systems.

Technical Specifications

Parameter	Specification
Model Number	3G3AX-MX2-ECT (Omron genuine part)
Communication Protocol	RS-422/485 (half-duplex)
Maximum Baud Rate	115,200 bps (configurable for legacy systems)
Physical Dimensions	60 mm (W) × 45 mm (H) × 20 mm (D)
Weight	50 g (lightweight for minimal mechanical load)
Electrical Characteristics	Isolated communication circuit, 0.5 W typical power draw
Environmental Ratings	Operational: -10°C to +50°C | Storage: -20°C to +65°C
Humidity Tolerance	20% to 90% RH (non-condensing)
Vibration Resistance	5.9 m/s² (10–55 Hz, compliant with IEC 60068-2-6)
Shock Resistance	98 m/s² (3 shocks per axis, meets IEC 60068-2-27)
Compatible Inverters	Omron MX2 series and select industrial inverters (verify model compatibility)
