3G3MX2-AB004-V2 Compact Inverter Drive, 0.4kW, 200V, 3-Phase, High-Performance Motor Control

Product Overview

The Omron 3G3MX2-AB004-V2 is a high-performance, compact inverter engineered for precise motor control in industrial automation applications. As part of the renowned MX2 series, this model delivers reliable operation, energy efficiency, and user-friendly configuration. Designed for single-phase input (100-120 VAC) and three-phase output (200-240 VAC), it is ideal for small to medium-sized motor-driven systems requiring variable speed control. The unit comes with a standard 1-year manufacturer's warranty, ensuring quality and durability.

Key Features

• Advanced Motor Control: Utilizes PWM (Sinusoidal) control for smooth and efficient motor operation with minimal harmonic distortion.
• Wide Frequency Range: Adjustable output frequency from 0.5 Hz to 400 Hz, enabling precise speed regulation for diverse applications.
• Compact Design: Space-saving dimensions (90 × 128 × 104.5 mm) and lightweight (1.2 kg) for easy integration into control panels and machinery.
• Robust Protection: Comprehensive safety features including overcurrent, overvoltage, undervoltage, and thermal overload protection to safeguard both the inverter and connected motor.
• Energy Efficient: Optimized power conversion reduces energy consumption, making it suitable for continuous operation in industrial environments.
• Durable Construction: Designed to operate in temperatures ranging from -10°C to 50°C, with storage capability from -20°C to 65°C.

Applications

The 3G3MX2-AB004-V2 is versatile and widely used in industrial automation, including:

• Material Handling: Conveyor belt systems, sorting machines, and automated guided vehicles (AGVs).
• Packaging Machinery: Filling machines, labeling systems, and shrink-wrapping equipment.
• HVAC & Fluid Control: Pumps, fans, and blowers requiring variable speed operation for energy savings.
• Food & Beverage: Processing equipment such as mixers, grinders, and bottling lines.
• Textile Industry: Spinning machines, looms, and other fabric-handling systems.

Technical Specifications

Parameter	Specification
Model Number	3G3MX2-AB004-V2
Input Voltage	100-120 VAC, single-phase (±10%)
Output Voltage	3-phase, 200-240 VAC (corresponds to input voltage)
Rated Output Current	4.0 A (continuous duty)
Power Rating	0.4 kW (0.5 HP)
Frequency Control Range	0.5 Hz to 400 Hz (programmable)
Control Method	Sinusoidal PWM (Pulse Width Modulation)
Efficiency	>95% (typical at full load)
Dimensions (W × H × D)	90 mm × 128 mm × 104.5 mm (3.54" × 5.04" × 4.11")
Weight	1.2 kg (2.65 lbs)
Operating Temperature	-10°C to 50°C (14°F to 122°F), non-freezing
Storage Temperature	-20°C to 65°C (-4°F to 149°F)
Protection Features	Overcurrent (150% for 60s), overvoltage, undervoltage, overheating (thermal shutdown)
Warranty	1 year limited warranty from date of purchase

Why Choose the Omron 3G3MX2-AB004-V2?

This inverter stands out for its reliability, compact design, and precise motor control, making it a preferred choice for OEMs and system integrators. Its wide frequency range and robust protection mechanisms ensure longevity in demanding industrial environments. The MX2 series is globally recognized for quality, and this model adheres to Omron's stringent manufacturing standards.
