C200HW-PA204 24V DC Power Supply Unit for Industrial Automation Systems

Omron C200HW-PA204 Power Supply Unit - Industrial Automation Solution

The Omron C200HW-PA204 represents the gold standard in industrial power supply technology, specifically engineered for mission-critical automation applications. As the backbone of Omron's legendary C200H series, this professional-grade power module delivers ultra-stable 5V DC power to programmable logic controllers (PLCs), high-density I/O modules, and industrial control systems. Engineered for 24/7 operation in demanding environments, the C200HW-PA204 features industrial-grade components, military-standard construction, and advanced protection circuitry. With its universal 100-240V AC input range and exceptional 130W output capacity, this power supply unit is the ideal choice for global manufacturing facilities, automated production lines, and heavy industrial applications. Backed by Omron's comprehensive 1-year manufacturer warranty, the C200HW-PA204 guarantees reliable performance in the most challenging operational conditions.

Key Features and Technical Advantages

• Universal Power Input: 100-240V AC (±10%) single-phase input with 50/60Hz auto-sensing capability ensures worldwide compatibility and stable operation despite voltage fluctuations
• High-Current DC Output: Delivers 5V DC at 26A (130W total power) with ±5% voltage tolerance, specifically designed to power multiple PLC modules simultaneously
• Industrial-Grade Engineering: Compact 90mm × 65mm × 95mm (W×H×D) footprint with professional DIN rail (35mm) mounting for space-efficient panel installation
• Rugged Construction: Lightweight 0.6kg aluminum alloy housing provides superior heat dissipation and vibration resistance in industrial environments
• Extended Temperature Range: Certified for continuous operation in 0°C to 55°C (32°F to 131°F) environments with 10-90% non-condensing humidity tolerance
• Advanced Protection Circuitry: Integrated safeguards against overload (150% for 3 seconds), overvoltage (6.5V cutoff), and short circuit conditions
• Regulatory Compliance: Meets UL508 industrial control equipment standards and CE directives for electromagnetic compatibility (EMC)
• Precision Power Delivery: Maintains ±1% voltage regulation under 10-100% load variations with less than 100mVp-p ripple noise

Industrial Applications and Use Cases

• Primary power source for Omron C200H series PLC systems in manufacturing automation
• Centralized power distribution unit for high-density I/O configurations in control cabinets
• Critical infrastructure component in automotive assembly line control systems
• Power management solution for robotic workcells and material handling systems
• Industrial PC and HMI backup power systems in process control applications
• Machine tool power distribution for CNC equipment and precision manufacturing
• Packaging machinery control systems requiring stable, high-current DC power
• Building automation systems and industrial IoT control nodes

Detailed Technical Specifications

Parameter	Specification
Manufacturer Part Number	C200HW-PA204 (Genuine Omron Component)
Input Voltage Range	100-240V AC (±10%), 50/60Hz automatic adaptation
Input Current	2.0A max @ 100V AC, 1.0A max @ 200V AC
Output Specifications	5V DC ±5% (4.75-5.25V), 26A continuous (130W max)
Power Conversion Efficiency	≥85% at full load (26A), typical 88% efficiency
Output Ripple Noise	<100mVp-p (20MHz bandwidth measurement)
Load Regulation	±1% (10-100% load variation, constant line voltage)
Line Regulation	±1% (input voltage variation from 100-240V AC)
Startup Time	<2 seconds (typical 1.5s at full load)
Hold-up Time	>20ms at full load (input voltage dropout)
Physical Dimensions	90mm (width) × 65mm (height) × 95mm (depth)
Weight	0.6kg (1.32 lbs) net weight
Operating Conditions	Temperature: 0°C to 55°C (32°F to 131°F) Storage: -25°C to 65°C (-13°F to 149°F) Humidity: 10% to 90% RH (non-condensing)
Safety Certifications	UL508 Industrial Control Equipment, CE Marked (EMC Directive)
Warranty Coverage	1-year manufacturer warranty against defects in materials and workmanship

System Integration and Installation

The Omron C200HW-PA204 power supply unit is designed for professional integration with Omron C200H series programmable controllers and compatible expansion I/O systems. The unit features industrial-grade screw terminal blocks (M3.5 screw size) for secure power connections, supporting wire sizes from 18 AWG to 12 AWG. The compact, convection-cooled design allows for high-density installations in standard control cabinets, with recommended 50mm clearance above and below the unit for optimal airflow. The integrated DIN rail mounting clip (35mm standard rail) enables tool-free installation and complies with industrial panel building standards. The C200HW-PA204 is rated for installation at altitudes up to 2000m (6562ft) without derating.

Reliability and Performance Characteristics

• Military-grade capacitors and industrial-rated components ensure a minimum 100,000-hour MTBF (Mean Time Between Failures)
• Precision voltage regulation maintains ±1% output accuracy despite line or load variations
• Thermal protection circuitry automatically initiates shutdown at 75°C (±5°C) with automatic recovery
• Low acoustic noise design (<35dB) suitable for control room installations
• Vibration resistant construction (10-55Hz, 0.375mm amplitude) for harsh industrial environments
• Designed for continuous 24/7 operation at full rated load capacity
