Compact 5-inch Programmable HMI Touch Panel with High Brightness LCD - NS5-SQ00B-V2
Compact 5-inch Programmable HMI Touch Panel with High Brightness LCD - NS5-SQ00B-V2
SKU:NS5-SQ00B-V2
Package size: 32X20X15CMRegular price
$430.00 USD
Regular price
Sale price
$430.00 USD
Unit price
/
per
Exclusive pricing & tailored solutions await!
Product Overview
The OMRON NS5-SQ00B-V2 is a 5.7-inch HMI (Human-Machine Interface) from the NS series, engineered for efficient and user-friendly interaction in industrial automation systems. It offers clear visualization, flexible connectivity, and reliable operation in demanding environments.
Key Features
- Display: 5.7-inch STN monochrome LCD (320 × 240 pixels)
- Backlight: Replaceable LED backlight
- Communication: RS-232C/RS-422A/485 ports for PLC and PC connectivity
- Touch Panel: Analog resistive touch screen
- Operating Voltage: 24 V DC (±10%)
- Power Consumption: 15 W (max)
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -20°C to 60°C
Applications
- Factory automation
- Production line monitoring
- Machine control interfaces
- Data display and input terminals
- Customizable operator panels
Technical Specifications
| Parameter | Value |
|---|---|
| Display Type | 5.7-inch STN monochrome LCD |
| Resolution | 320 × 240 pixels (QVGA) |
| Touch Panel | Analog resistive |
| Backlight | LED (replaceable) |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | 15 W (max) |
| Communication Ports | RS-232C, RS-422A/485 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Humidity Range | 10% to 90% (non-condensing) |
| Dimensions (W × H × D) | 142 mm × 98 mm × 56 mm |
| Weight | Approx. 500 g |
