E6B2-CWZ6C 300P/R 2M Incremental Rotary Encoder, 300 Pulses, 2M Cable

Product Overview

The E6B2-CWZ6C 300P/R 2M is an incremental rotary encoder designed for precise position and speed detection. It belongs to the E6B2 series, which is known for reliable performance in industrial automation applications. This encoder provides 300 pulses per revolution (PPR) and features a resolution of up to 1200 pulses when using the quadrature output (X4 counting method). The device includes a shielded cable (2 meters in length) for noise-resistant signal transmission.

Key Features

• Resolution: 300 pulses per revolution (PPR)
• Output Type: Line driver (differential output)
• Supply Voltage: 5 VDC ±5%
• Current Consumption: 80 mA max
• Output Phase: A, B, and Z (index) phases
• Max. Response Frequency: 100 kHz
• Operating Temperature: -10°C to +70°C
• Storage Temperature: -25°C to +85°C
• Protection Rating: IP50
• Shaft Diameter: 6 mm
• Weight: Approx. 300 g
• Cable Length: 2 meters (shielded)

Applications

• Industrial automation for motor speed feedback
• CNC machinery for position control
• Robotics for precise angular measurement
• Conveyor belt speed monitoring
• Packaging equipment for motion synchronization

Technical Specifications
