High-Capacity R88D Servo Drive with EtherCAT, 8.0kW, KN08H Model
High-Capacity R88D Servo Drive with EtherCAT, 8.0kW, KN08H Model
SKU:R88D-KN08H-ECT-Z
Package size: 27X23X18CMProduct Overview
The R88D-KN08H-ECT-Z from Omron is a high-performance servo drive engineered for precision motion control in demanding industrial automation environments. As part of Omron's renowned KN series, this servo drive delivers exceptional accuracy, reliability, and energy efficiency for controlling servo motors with advanced feedback systems. Its compact design and robust construction make it ideal for space-constrained installations while maintaining industrial-grade durability.
Key Features and Benefits
- High-Precision Control: Supports 17-bit incremental encoder feedback (131,072 pulses/revolution) for ultra-fine positioning accuracy in critical applications.
- Optimized Power Delivery: 200-230 VAC single-phase input with 8.0 A peak (3.0 A continuous) output current ensures stable operation under varying load conditions.
- Space-Efficient Design: Compact 45 × 130 × 104 mm (W×H×D) footprint allows for flexible mounting in control panels with limited space.
- Advanced Motion Control: Pulse train input interface enables precise position control compatible with various PLC and motion controllers.
- Energy Efficient: Maximum power consumption of 750W with intelligent power management features to reduce operational costs.
- Industrial Protection: IP20 rating provides basic protection against solid objects while maintaining optimal thermal performance.
- Reliable Operation: Designed for continuous operation in industrial environments with 0°C to 55°C temperature range and 10-90% humidity (non-condensing).
- Standard Warranty: Backed by Omron's 1-year manufacturer warranty for peace of mind.
Industrial Applications
The R88D-KN08H-ECT-Z servo drive is engineered for diverse motion control applications across multiple industries:
- CNC Machinery: Provides precise axis control for milling, turning, and grinding operations
- Industrial Robotics: Enables accurate positioning for robotic arms and automated assembly systems
- Packaging Automation: Delivers consistent performance for filling, labeling, and packaging lines
- Textile Manufacturing: Offers smooth motion control for spinning, weaving, and fabric handling equipment
- Semiconductor Production: Ensures micron-level precision for chip handling and placement systems
- Material Handling: Provides reliable control for conveyor systems and automated storage/retrieval systems
Detailed Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | R88D-KN08H-ECT-Z |
| Power Supply | 200-230 VAC ±10%, single-phase, 50/60 Hz |
| Output Current (Peak/Rated) | 8.0 A peak / 3.0 A continuous |
| Control Method | Pulse train input (differential line driver or open collector) |
| Feedback System | Incremental encoder (17-bit resolution, 131,072 PPR) |
| Control Modes | Position control, speed control, torque control |
| Communication Interface | Pulse input (Max. 500 kpps), CW/CCW or pulse + direction |
| Protection Functions | Overcurrent, overload, overvoltage, undervoltage, overspeed, encoder error, regenerative error |
| Physical Dimensions | 45 mm (W) × 130 mm (H) × 104 mm (D) |
| Weight | 0.8 kg |
| Power Consumption | 750 W maximum |
| Protection Rating | IP20 (IEC 60529) |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -15°C to 70°C (5°F to 158°F) |
| Humidity Range | 10% to 90% RH (non-condensing) |
| Vibration Resistance | 4.9 m/s² (0.5 G) at 10-60 Hz in XYZ directions |
| Warranty Period | 1 year manufacturer warranty |
| Compliance Standards | CE, UL, cUL (Note: Verify specific certifications for your region) |
System Integration
The R88D-KN08H-ECT-Z is designed for seamless integration with Omron's KN series servo motors and compatible with various industrial control systems. Its standard pulse train input makes it compatible with most PLCs and motion controllers in the market. For optimal performance, we recommend pairing with Omron's R88M-K series servo motors and configuring through Omron's dedicated setup software.
Installation Considerations
When installing the R88D-KN08H-ECT-Z servo drive:
- Ensure adequate ventilation space around the unit (minimum 50mm clearance on all sides)
- Mount in a clean, dry environment protected from excessive dust and moisture
- Use proper grounding techniques to minimize electrical noise interference
- Follow all local electrical codes and regulations for installation
- Refer to the official Omron technical documentation for wiring diagrams and safety precautions
