High-Speed NJ501-1300 Automation Controller with EtherCAT Support
High-Speed NJ501-1300 Automation Controller with EtherCAT Support
SKU:NJ501-1300
Package size: 17X17X14CMOmron NJ501-1300 Machine Automation Controller | High-Performance Industrial PLC
Product Overview
The Omron NJ501-1300 represents the pinnacle of industrial automation control technology, delivering exceptional processing power and precision for demanding manufacturing applications. As part of Omron's premium NJ Series of machine automation controllers, this advanced PLC solution combines a powerful 1.2 GHz dual-core processor with extensive I/O capabilities to handle complex motion control sequences and high-speed automation tasks with unparalleled reliability. Engineered specifically for industrial environments, the NJ501-1300 features rugged construction with vibration-resistant components and wide temperature tolerance (0°C to 55°C), ensuring consistent performance in challenging conditions. The controller's modular architecture supports seamless integration with Omron's extensive range of NJ-series I/O modules, enabling customized system configurations for diverse automation requirements. With its compact footprint (90 × 130 × 65 mm) and flexible mounting options (DIN rail or panel), the NJ501-1300 optimizes control cabinet space while providing industrial-grade processing power. This unit comes with Omron's standard 1-year manufacturer warranty, covering defects in materials and workmanship under normal operating conditions.
Key Features and Benefits
- Advanced Processing Architecture: Dual-core 1.2 GHz industrial CPU with real-time operating system delivers deterministic performance for precision motion control and high-speed automation tasks, achieving cycle times as low as 1ms for critical control loops.
- Scalable I/O System: Base configuration supports 256 I/O points with expansion capabilities through Omron's NJ-series modules, including digital I/O (up to 32 points per module), analog inputs/outputs, and specialty modules for temperature control and high-speed counters.
- Optimized Industrial Design: Compact 90 × 130 × 65 mm form factor with only 500g weight features robust metal housing, DIN rail mounting compatibility (35mm), and panel mounting options for flexible installation in control cabinets.
- Energy-Efficient Operation: 24V DC power supply (±10% tolerance) with intelligent power management maintains low operational consumption (20W typical, 30W peak) while supporting industrial power fluctuations.
- Enhanced Memory Configuration: 512MB DDR3 RAM ensures smooth execution of complex control programs, while 2GB flash storage provides ample space for application programs, motion profiles, and historical data logging.
- Comprehensive Communication Suite: Integrated 100BASE-TX Ethernet port (10/100Mbps) for network connectivity, USB 2.0 host port for programming and maintenance, plus RS-232C serial port for legacy device integration.
- Industrial-Grade Reliability: Designed for continuous operation in standard industrial environments with protection against vibration (10-55Hz, 0.075mm amplitude) and electrical noise (1500Vp-p noise voltage, 1μs pulse width).
- Certified Compliance: Meets international standards including CE, UL, and cUL certifications for industrial control equipment, ensuring global deployment compatibility.
Industrial Applications
The Omron NJ501-1300 automation controller delivers precision control across diverse industrial automation scenarios:
- Advanced Robotics Systems: Synchronized multi-axis control for articulated robots, SCARA systems, and collaborative robotics applications with precise trajectory planning and motion profiling.
- High-Speed Packaging Lines: Integrated control for form-fill-seal machines, cartoners, case packers, and labeling systems requiring precise timing coordination between mechanical components.
- Precision Machine Tools: Complex motion control for CNC machining centers, lathes, and grinding machines with spindle synchronization and toolpath optimization capabilities.
- Pharmaceutical Production: GMP-compliant automation for tablet compression, sterile filling lines, and secondary packaging equipment with precise process parameter control.
- Automated Material Handling: Intelligent control for AS/RS systems, conveyor networks, and sortation equipment with integrated barcode reading and tracking functionality.
- Quality Inspection Systems: Tight integration with machine vision systems for automated defect detection, dimensional verification, and surface inspection applications.
- Process Automation: Precise batch control for chemical processing, food production, and other continuous manufacturing operations requiring recipe management and parameter tracking.
- Semiconductor Manufacturing: Ultra-precise motion control for wafer handling, die bonding, and other cleanroom automation applications demanding nanometer-level positioning accuracy.
Detailed Technical Specifications
| Specification | Technical Details |
|---|---|
| Manufacturer Part Number | NJ501-1300 (Genuine Omron Automation Component) |
| Physical Dimensions (W×H×D) | 90 mm × 130 mm × 65 mm (3.54" × 5.12" × 2.56") |
| Unit Weight | 500 grams (1.1 lbs) excluding expansion modules |
| Power Supply Requirements | 24V DC nominal (21.6V to 26.4V operating range) |
| Power Consumption Characteristics | 20W typical operation (30W maximum under full load conditions) |
| Processing Unit Architecture | Industrial-grade 1.2 GHz dual-core CPU with dedicated motion control coprocessor |
| Memory Specifications | 512MB DDR3 SDRAM (program execution) + 2GB NAND flash (storage) |
| Base I/O Capacity | 256 points (configurable through NJ-series expansion modules) |
| Communication Interfaces |
|
| Environmental Specifications |
|
| Mechanical Installation | Standard 35mm DIN rail mounting (EN 60715 compliant) or direct panel mounting with M4 screws |
| Regulatory Compliance | CE, UL, cUL, FCC Class A, RoHS compliant |
| Warranty Information | 1-year limited manufacturer warranty from date of purchase (Omron standard terms apply) |
