NB7W-TW01B-V1 - 7-Inch Industrial Touch Display Unit for Automation Control

The Omron NB7W-TW01B-V1 is a rugged 7-inch touch display unit engineered for demanding industrial automation environments. As part of Omron's premium HMI (Human-Machine Interface) product line, this operator terminal delivers reliable performance for machine control and process visualization applications. The unit features a high-brightness TFT LCD with optimal viewing angles and a responsive touch interface, making it ideal for factory floor operations.

Key Features and Benefits

• High-Visibility Display: 7-inch TFT LCD with 800 × 480 WVGA resolution provides crisp, clear graphics and text visibility even in challenging lighting conditions
• Durable Touch Interface: Resistive touch screen supports reliable operation with gloves or stylus, essential for industrial environments
• Robust Construction: IP65-rated front panel protection against dust and water jets ensures reliable operation in harsh conditions
• Versatile Connectivity: Comprehensive I/O options including USB 2.0 (Type A host and Type B device ports), RS-232C serial interface, and 10/100BASE-TX Ethernet for flexible system integration
• Compact Design: Space-saving 200 × 146 × 47 mm (W×H×D) dimensions with panel-mount capability for efficient control panel installation
• Stable Power Supply: 24V DC (±10%) input with maximum 15W power consumption for energy-efficient operation
• Wide Temperature Range: Operational from 0°C to 50°C (-20°C to 60°C storage) for reliable performance in varied industrial environments
• Standard Warranty: Backed by Omron's 1-year manufacturer warranty for peace of mind

Industrial Applications

The NB7W-TW01B-V1 touch display is designed for diverse automation applications including:

• Factory automation systems and production line monitoring
• Machine control panels for CNC equipment, packaging machines, and assembly systems
• Process visualization and real-time data monitoring in manufacturing plants
• Equipment parameter adjustment and operational status display
• Seamless integration with Omron PLCs and other industrial control devices
• Quality control stations and production data logging interfaces

Detailed Technical Specifications

Specification	Detail
Model Number	NB7W-TW01B-V1
Display Technology	7-inch TFT color LCD with LED backlight
Display Resolution	800 × 480 pixels (WVGA)
Touch Panel Type	Analog resistive (supports glove/stylus operation)
Physical Dimensions	200 mm (W) × 146 mm (H) × 47 mm (D)
Panel Cutout Dimensions	192 mm (W) × 138 mm (H)
Unit Weight	Approximately 600 grams
Power Requirements	24 V DC (±10%), 15W maximum consumption
Environmental Ratings	IP65 front protection, NEMA 4X equivalent
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Communication Interfaces	USB 2.0 Host (Type A), USB 2.0 Device (Type B), RS-232C (D-Sub 9-pin), Ethernet 10/100BASE-TX (RJ45)
Vibration Resistance	10-25Hz (X,Y,Z directions, 2G amplitude)
Shock Resistance	30G (11ms duration, half-sine wave)
Warranty Period	1 year from date of purchase

System Compatibility and Integration

The NB7W-TW01B-V1 is designed for seamless integration with Omron's industrial automation products including NJ/NX-series machine controllers, CP1E/CP1L/CP1H programmable controllers, and various other industrial devices. The unit supports multiple communication protocols for flexible system configuration.

Installation and Mounting

This HMI unit features a panel-mount design with front IP65 protection. The compact form factor allows for space-efficient installation in control cabinets or machine panels. The display offers excellent viewing angles (typically 70° up/down/left/right) for optimal visibility in various installation positions.
