Omron NS10-TV00-V2 Programmable Terminal - Industrial HMI with 10.4" TFT Display

Comprehensive Product Overview

The Omron NS10-TV00-V2 represents the pinnacle of industrial human-machine interface technology, combining robust construction with advanced visualization capabilities. As part of Omron's premium NS Series of programmable terminals, this industrial-grade HMI solution delivers exceptional performance for automation, process control, and machine interface applications across multiple industries. Engineered for reliability in harsh environments, the NS10-TV00-V2 facilitates precise equipment monitoring, real-time data visualization, and efficient process control through its intuitive touchscreen interface. The terminal's rugged design and advanced features help manufacturing facilities, processing plants, and machine builders optimize operational efficiency while minimizing unplanned downtime.

Advanced Features and Operational Benefits

• High-Performance Display System: 10.4-inch TFT color LCD with 640 x 480 (VGA) resolution and LED backlight technology ensures superior visibility with 16-bit color depth (65,536 colors) for clear differentiation of process indicators, alarm states, and control elements under various lighting conditions.
• Industrial-Optimized Touch Interface: High-sensitivity 4-wire resistive touchscreen provides reliable operation with gloved hands and maintains performance in environments with dust, moisture, and electromagnetic interference (EMI).
• Powerful Processing Architecture: 32-bit RISC processor with dedicated graphics controller delivers rapid screen refresh rates (under 500ms for full screen updates) and smooth operation of complex HMI applications with multiple simultaneous processes.
• Expanded Memory Configuration: 15 MB non-volatile flash memory provides ample storage for application programs, historical data logging (up to 10,000 records), and recipe management without requiring additional memory expansion.
• Comprehensive Connectivity Options: Standard RS-232C (9-pin D-sub) serial port and USB Type-B host port enable direct connection to Omron PLCs (including CJ/CS/NJ series) and third-party industrial equipment using industry-standard protocols.
• Industrial-Grade Protection: Front panel meets IP65 (NEMA 4X equivalent) protection standards with gasket-sealed construction that resists dust ingress and low-pressure water jets, making it suitable for washdown environments.
• Reliable Power Management: 24 VDC ±10% power input (20.4 to 26.4 VDC operational range) with reverse polarity protection and less than 30W maximum power consumption ensures stable operation in industrial power environments with typical fluctuations.
• Extended Environmental Tolerance: Operational temperature range of 0°C to 50°C (32°F to 122°F) with 10-90% relative humidity (non-condensing) and storage capability from -20°C to 60°C (-4°F to 140°F) for deployment in unregulated industrial spaces.
• Mechanical Durability: Vibration resistance of 10-25 Hz at 1G amplitude and 25-55 Hz at 0.3mm amplitude, plus shock resistance of 15G acceleration (11ms duration) compliant with IEC 61131-2 standards for industrial equipment.
• Manufacturer Warranty: Backed by Omron's comprehensive 1-year warranty against manufacturing defects when used according to specifications (Omron part number NS10-TV00-V2).

Industrial Application Solutions

• Automotive Manufacturing Systems: Provides real-time monitoring and control for robotic welding cells, assembly lines, and quality inspection stations with high-resolution visualization of production metrics and alarm conditions.
• Pharmaceutical Process Control: Compliant interface solution for cleanroom environments requiring precise monitoring of batch processes, temperature-controlled systems, and validation parameters.
• Packaging Machinery: Serves as the primary operator interface for form-fill-seal machines, labeling systems, and case packers with intuitive recipe management and production counting functions.
• Water Treatment Facilities: Robust HMI solution for SCADA applications monitoring pump stations, filtration systems, and chemical dosing equipment in municipal and industrial water plants.
• Food Processing Equipment: IP65-rated front panel withstands frequent washdowns while providing clear visualization of processing parameters, CIP cycles, and production schedules in meat, dairy, and beverage applications.
• Material Handling Systems: Central control interface for conveyor networks, automated storage/retrieval systems, and sortation equipment with real-time tracking of throughput and system status.

Precision Technical Specifications

Technical Parameter	Detailed Specification
Product Identification	Omron NS Series Programmable Terminal, Model NS10-TV00-V2 (factory-confirmed designation)
Visual Display System	10.4" diagonal TFT active matrix color LCD with LED backlight (16:9 aspect ratio), 200 cd/m² brightness, 400:1 contrast ratio
Display Resolution	640 (H) x 480 (V) pixels (VGA standard) with 16-bit color processing
Touchscreen Technology	4-wire analog resistive touch panel with 4096 x 4096 resolution, supports single-point activation with stylus, fingernail, or gloved hand
Processing Architecture	32-bit RISC processor with dedicated graphics accelerator, 16 MB system memory
Application Memory	15 MB user-accessible flash memory for program storage and data logging
Communication Interfaces	1 x RS-232C (9-pin D-sub female, 115.2 kbps max), 1 x USB 2.0 Type-B (host port for peripheral connection)
Physical Dimensions (W x H x D)	290 mm x 220 mm x 60 mm (11.42" x 8.66" x 2.36") including mounting flanges
Panel Cutout Requirements	276 mm x 206 mm (10.87" x 8.11") minimum rectangular opening for proper DIN rail mounting
Product Weight	1.5 kg (3.31 lbs) including all mounting hardware and terminal blocks
Electrical Specifications	24 VDC nominal input (20.4-26.4 VDC operational range), 1.25A typical current draw, 30W maximum power dissipation
Environmental Protection	IP65 front panel rating (complete protection against dust ingress, low-pressure water jets from any direction)
Operational Climate Range	0°C to 50°C (32°F to 122°F) with 10-90% relative humidity (non-condensing)
Storage Conditions	-20°C to 60°C (-4°F to 140°F) in original packaging with desiccant
Mechanical Durability	Vibration resistance per IEC 60068-2-6 (10-25Hz at 1G, 25-55Hz at 0.3mm), shock resistance per IEC 60068-2-27 (15G, 11ms)
Regulatory Compliance	CE, UL/cUL Class I Division 2, FCC Part 15 Subpart B Class A, compliant with RoHS directives
Warranty Coverage	Omron standard 1-year limited warranty from date of purchase (proof of purchase required)

System Integration and Programming

The Omron NS10-TV00-V2 programmable terminal offers seamless integration with Omron's comprehensive automation ecosystem, including direct compatibility with CJ/CS/NJ series PLCs through native protocol support. The unit's communication architecture supports multiple industrial protocols including Host Link, NT Link (1:1 and 1:N), and Modbus RTU for connectivity with third-party control systems. Programming is accomplished using Omron's CX-Designer software (sold separately), which provides advanced development tools for creating customized operator interfaces with alarm management, data trending, and recipe handling capabilities. The terminal's ruggedized design ensures reliable operation when integrated into control panels, machinery, and process skids subject to vibration, temperature fluctuations, and industrial contaminants.
