NS10-TV00B-V2 10-inch HMI Touch Panel with V2 Firmware for Industrial Automation

Omron NS10-TV00B-V2 Programmable Terminal - Industrial-Grade HMI Solution

The Omron NS10-TV00B-V2 represents the pinnacle of industrial human-machine interface (HMI) technology, designed specifically for demanding automation environments. As part of Omron's premium NS Series, this programmable terminal combines robust construction with advanced functionality to deliver reliable performance in factory automation, process control, and machine operation applications. The unit features a high-resolution 10.4-inch TFT color display with VGA (640 x 480 pixels) resolution, providing exceptional clarity for monitoring complex industrial processes. With its IP65-rated front panel protection and industrial-grade components, the NS10-TV00B-V2 maintains operational integrity in challenging conditions including dust, moisture, and temperature variations.

Comprehensive Feature Set for Industrial Automation

• High-Performance Display: 10.4-inch TFT color LCD with 640 x 480 VGA resolution and 16-bit color depth delivers crisp, detailed visualization of process data, alarms, and system diagnostics
• Industrial Power Design: 24 VDC (±10%) input voltage range with maximum 45W power consumption ensures stable operation across varying power conditions
• Space-Efficient Design: Compact 290 x 222 x 56 mm (11.42" x 8.74" x 2.20") dimensions and 1.8 kg weight enable flexible panel mounting in control cabinets and machinery
• Versatile Communication Options: Equipped with 1x RS-232C (9-pin D-sub) and 1x RS-422/485 (terminal block) ports for seamless integration with PLCs, sensors, and industrial networks
• Multi-Protocol Compatibility: Supports industry-standard communication protocols including Omron's own Host Link protocol for direct PLC connectivity
• Extended Operational Range: Certified for continuous operation from 0°C to 50°C (32°F to 122°F) with storage capability from -20°C to 60°C (-4°F to 140°F)
• Rugged Construction: Front panel meets IP65 protection standard (IEC 60529) for resistance against dust ingress and low-pressure water jets from any direction
• Mechanical Durability: Complies with IEC 61131-2 standards for vibration (10-25Hz, 1.0mm amplitude) and shock resistance (147 m/s², 15G for 11ms)
• Manufacturer Warranty: Backed by Omron's standard 1-year limited warranty from date of purchase for defects in materials and workmanship

Industrial Applications and Use Cases

The Omron NS10-TV00B-V2 programmable terminal delivers exceptional performance across diverse industrial automation scenarios:

• Manufacturing Automation: Centralized monitoring and control of production lines, robotic cells, and assembly systems in automotive, electronics, and consumer goods manufacturing
• Process Control Systems: Real-time visualization of batch processes, temperature profiles, and equipment status in chemical, pharmaceutical, and food processing plants
• Industrial Machinery: Operator interface for injection molding machines, CNC equipment, packaging systems, and other capital equipment requiring robust HMI solutions
• Material Handling Automation: Control and diagnostics for conveyor systems, automated storage/retrieval systems (AS/RS), and warehouse automation
• Facility Management: Energy monitoring and equipment status visualization for industrial plants, water treatment facilities, and power distribution systems
• Quality Control Stations: Data entry and process verification points in manufacturing quality assurance workflows

Detailed Technical Specifications

Category	Specification Details
Product Model	Omron NS Series NS10-TV00B-V2 Programmable Terminal
Display Technology	10.4-inch TFT color LCD with analog resistive touch panel
Display Characteristics	640 x 480 pixel resolution (VGA), 16-bit color (65,536 colors), 300 cd/m² brightness
Electrical Specifications	24 VDC nominal input voltage (21.6-26.4V range), 45W maximum power consumption, 1.9A typical current draw
Physical Dimensions	290 mm (W) x 222 mm (H) x 56 mm (D) / 11.42" x 8.74" x 2.20" (excluding mounting fixtures)
Weight	1.8 kg (3.97 lbs) net weight
Communication Ports	1x RS-232C (9-pin D-sub male), 1x RS-422/485 (terminal block connector)
Environmental Protection	IP65 rating (front panel only) per IEC 60529, NEMA 4X equivalent
Operating Conditions	Temperature: 0°C to 50°C (32°F to 122°F), Humidity: 10% to 90% RH (non-condensing)
Storage Conditions	Temperature: -20°C to 60°C (-4°F to 140°F), Humidity: 10% to 90% RH (non-condensing)
Mechanical Durability	Vibration: 10-25Hz, 1.0mm amplitude (IEC 61131-2 compliant) Shock: 147 m/s² (15G) for 11ms in X, Y, Z directions (IEC 61131-2 compliant)
Warranty Information	1-year limited warranty covering defects in materials and workmanship under normal use

System Integration and Operational Advantages

The Omron NS10-TV00B-V2 programmable terminal offers significant advantages for industrial automation systems:

• Enhanced Process Visibility: High-resolution color display provides clear visualization of complex automation processes with customizable screen layouts
• Reliable Industrial Performance: Designed for 24/7 operation in harsh industrial environments with protection against electrical noise and power fluctuations
• Simplified System Integration: Native compatibility with Omron PLCs including CJ, CS, and CP series through Host Link protocol
• Durable Touch Interface: Analog resistive touch panel rated for 1 million operations ensures long-term reliability in high-use environments
• Flexible Mounting Options: Panel-mount design with standard cutout dimensions for easy installation in control panels and machinery
• Reduced Downtime: Robust construction minimizes failures in demanding industrial applications, supported by Omron's 1-year warranty

Compliance and Standards

The NS10-TV00B-V2 meets rigorous industrial standards including:

• CE Marking (EMC Directive, Low Voltage Directive)
• UL/cUL Listed (UL 61010-1, CSA C22.2 No. 61010-1)
• IEC 61131-2 (Programmable Controllers - Equipment Requirements and Tests)
• IEC 60529 (IP65 front panel rating)
• FCC Part 15 Subpart B Class A (for industrial environments)
