Omron NS5-SQ10-V2 Programmable Terminal (PT) - Industrial HMI with 5.7" Color Touch Display

High-Performance Compact Human-Machine Interface for Industrial Automation

The Omron NS5-SQ10-V2 represents the next generation of compact programmable terminals, offering superior operator interface capabilities for industrial automation systems. This 5.7-inch HMI solution combines robust construction with advanced functionality, making it ideal for machine control, process monitoring, and system visualization in demanding manufacturing environments. Engineered for reliability and ease of integration, the NS5-SQ10-V2 delivers exceptional performance in space-constrained applications while maintaining Omron's renowned quality standards.

Advanced Technical Features

• High-Visibility Display: 5.7-inch TFT color LCD with 320x240 resolution and 256-color capability (supports 32,768-color images for enhanced visualization)
• Durable Touch Interface: Matrix resistive membrane touch panel with 300 switch points for precise operator control
• Rugged Industrial Design: IP65-rated front panel protection against dust, oil, and liquid ingress for reliable operation in harsh conditions
• Comprehensive Connectivity: Dual RS-232C serial ports for simultaneous PLC communication and peripheral connections
• Data Management: Integrated CompactFlash card slot (Type I) for expanded data storage and backup capabilities
• Easy Configuration: USB slave port (Type B) for rapid screen transfer and programming
• Wide Voltage Range: 24VDC power input with 20.4-27.6VDC operating range for stable performance in fluctuating power conditions
• Extended Service Life: Backlight rated for 50,000 hours (typical) at 25°C ambient temperature

Detailed Technical Specifications

Category	Specification Details
Model Number	NS5-SQ10-V2 (Omron genuine part)
Display Technology	5.7" TFT active matrix color LCD with LED backlight
Display Area	115.2mm (W) × 86.4mm (H)
Pixel Configuration	320 (H) × 240 (V) dots
Color Reproduction	256 simultaneous colors (32,768 color palette for image display)
Touch Panel Type	4-wire resistive membrane (matrix configuration with 300 switch points)
Communication Interfaces	2 × RS-232C (9-pin D-sub), 1 × USB 1.1 Type B (slave), CompactFlash slot (Type I)
Electrical Specifications	24VDC ±10% (20.4-27.6VDC range), 15W maximum power consumption
Environmental Ratings	Operating temperature: 0 to 50°C (horizontal mounting), Storage temperature: -20 to 60°C, Humidity: 10% to 90% RH (non-condensing)
Protection Standards	Front panel: IP65 (NEMA 4X equivalent), Oil-resistant coating
Physical Dimensions	160mm (W) × 130mm (H) × 56mm (D) (excluding mounting fixtures)
Weight	1.0kg maximum (including packaging)
Warranty	1-year manufacturer warranty against defects in materials and workmanship

Industrial Application Scenarios

The Omron NS5-SQ10-V2 programmable terminal excels in diverse industrial automation applications where reliable operator interface is critical:

• Machine Control Systems: Intuitive interface for CNC machines, injection molding equipment, and robotic workcells
• Production Monitoring: Real-time visualization of assembly line status, production counts, and quality metrics
• Process Industries: Control and monitoring of batch processes, mixing operations, and temperature-controlled systems
• Packaging Machinery: Operator interface for fill-level monitoring, speed control, and fault diagnostics
• Material Handling: Conveyor system control, inventory tracking, and warehouse automation
• Food & Beverage Processing: Hygienic design suitable for washdown environments with proper enclosure

Technical Advantages and Differentiators

The NS5-SQ10-V2 programmable terminal delivers superior performance through its combination of robust hardware and intelligent design features:

Enhanced Visibility: The high-contrast 256-color display ensures excellent readability in various lighting conditions, from dim factory floors to brightly lit environments. The display supports imported images with 32,768-color depth for detailed graphical representations of processes and equipment.

Reliable Touch Operation: The matrix resistive touch panel provides precise positional accuracy (±2mm maximum error) with a durable surface capable of withstanding over 1 million operations per switch point. The oil-resistant coating maintains responsiveness in industrial environments where lubricants or coolants may be present.

Flexible Communication: With two independent RS-232C ports, the NS5-SQ10-V2 can simultaneously communicate with a PLC and peripheral devices such as barcode readers or printers. The CompactFlash slot supports standard Type I cards up to 2GB capacity for data logging, recipe storage, and screen backup.

Simplified Integration: The unit's 24VDC power input matches standard industrial control voltages, while the wide operating range ensures stable performance during voltage fluctuations. The compact footprint (160×130×56mm) allows installation in tight spaces without compromising functionality.

System Compatibility and Integration

The NS5-SQ10-V2 offers seamless integration with Omron's automation ecosystem and third-party systems:

• Omron PLC Connectivity: Native support for CS/CJ/CP-series PLCs via Host Link protocol
• Legacy System Support: Compatible with C200HX/HG/HE(-Z) series PLCs using dedicated communication drivers
• Temperature Control: Direct interface with Omron E5□C/□N temperature controllers via CompoWay/F protocol
• Third-Party Integration: Modbus RTU protocol support for connection with non-Omron devices

Development Environment: The NS5-SQ10-V2 is programmed using Omron's CX-Designer software (sold separately), which provides comprehensive tools for screen creation, animation, alarm configuration, and data logging. The software supports tag-based addressing for efficient project development and includes extensive library of pre-configured graphic elements.

Quality Assurance and Reliability

Every NS5-SQ10-V2 programmable terminal undergoes rigorous quality testing to ensure compliance with industrial standards. The unit's design incorporates:

• Vibration resistance: 10-57Hz, 0.075mm amplitude (57-150Hz, 9.8m/s² acceleration)
• Shock resistance: 147m/s² (3 times each in 6 directions)
• Noise immunity: 1,000Vp-p noise voltage (1μs pulse width, 30-100Hz)
• Dielectric strength: 1,500VAC for 1 minute between power terminals and ground

The product is backed by Omron's standard 1-year warranty covering manufacturing defects. For optimal performance, we recommend installation in environments with minimal conductive dust and corrosive gases.
