NS8-TV00B-V2 8-inch Touch Screen Panel with V2 Firmware for Industrial Automation

Omron NS8-TV00B-V2 Programmable Terminal - Industrial-Grade HMI Solution

The Omron NS8-TV00B-V2 represents the pinnacle of industrial human-machine interface (HMI) technology from Omron's acclaimed NS Series. This 8.4-inch programmable terminal combines robust construction with advanced functionality to deliver superior machine visualization and control in demanding industrial automation environments. Engineered for reliability and precision, the NS8-TV00B-V2 facilitates real-time process monitoring, data visualization, and seamless integration with industrial control systems while maintaining Omron's renowned quality standards.

Comprehensive Features and Operational Advantages

• High-Resolution Industrial Display: 8.4-inch TFT color LCD with 800 × 600 SVGA resolution and 16.7 million color depth provides exceptional clarity for monitoring complex automation processes
• Industrial-Grade Touch Interface: Resistive touch screen technology ensures reliable operation in all industrial conditions, including operation with work gloves or in environments with moisture and vibration
• Versatile Communication Ports: Comprehensive connectivity options including USB 2.0 (1 Host port for peripherals, 1 Slave port for programming), RS-232C serial interface, and 10/100BASE-T Ethernet for flexible system integration
• Rugged Environmental Protection: Front panel rated IP65 for complete protection against dust ingress and low-pressure water jets from any direction, ensuring durability in harsh manufacturing environments
• Space-Efficient Design: Compact 225 × 178 × 60 mm (W×H×D) dimensions with panel-mount configuration optimizes control panel space utilization while maintaining full functionality
• Extended Temperature Operation: Reliable performance across industrial temperature ranges from 0°C to 50°C (32°F to 122°F) with storage capability from -20°C to 60°C (-4°F to 140°F)
• Industrial Power Design: 24 VDC (±10%) power input with maximum 25W consumption ensures compatibility with standard industrial power systems while maintaining energy efficiency
• Mechanical Durability: Designed to withstand industrial vibration (10-150 Hz) and shock (147 m/s² in all axes) without performance degradation
• Manufacturer Warranty: Backed by Omron's standard 1-year warranty from date of purchase, covering manufacturing defects under normal operating conditions

Industrial Automation Applications

The Omron NS8-TV00B-V2 programmable terminal is engineered for diverse industrial automation scenarios including:

• Centralized monitoring and control of automated production lines in manufacturing facilities
• Process visualization and parameter adjustment in continuous process industries
• Machine operator interfaces for CNC equipment, packaging machinery, and material handling systems
• Real-time production data display and historical trend visualization for quality control
• Equipment diagnostic interfaces for predictive maintenance systems
• Batch process control and recipe management in food & beverage and pharmaceutical applications
• Integration with SCADA systems for plant-wide monitoring and control
• Alarm management and event logging for critical industrial processes

Precision Engineering Specifications

Specification Category	Technical Details
Product Model	Omron NS Series NS8-TV00B-V2 Programmable Terminal
Display Technology	8.4-inch active matrix TFT color LCD with 800 × 600 pixel resolution, 16.7 million color palette, 300 cd/m² brightness
Touch Panel Specifications	Analog resistive touch screen with minimum 1 million touch operations life, supports operation with gloves or stylus
Communication Interfaces	USB 2.0: 1 × Host port (Type A connector), 1 × Slave port (Type B connector) Serial: 1 × RS-232C (D-Sub 9-pin male) Network: 10/100BASE-T Ethernet (RJ45 connector)
Physical Dimensions	225 mm (width) × 178 mm (height) × 60 mm (depth) excluding mounting fixtures
Panel Cutout Dimensions	211 mm (width) × 164 mm (height) for proper flush mounting
Weight	1.2 kg (2.65 lbs) net weight excluding packaging
Power Specifications	24 VDC ±10% input voltage range, 25W maximum power consumption, reverse polarity protection
Environmental Specifications	Operating Temperature: 0°C to 50°C (32°F to 122°F) Storage Temperature: -20°C to 60°C (-4°F to 140°F) Operating Humidity: 10% to 90% RH (non-condensing) Altitude: Up to 2000 m operation
Protection Standards	Front panel IP65 compliant (IEC 60529), NEMA 4X equivalent when properly panel-mounted
Mechanical Durability	Vibration Resistance: 10-57 Hz at 0.075 mm amplitude, 57-150 Hz at 9.8 m/s² acceleration (IEC 60068-2-6) Shock Resistance: 147 m/s² (15G) in X, Y, Z directions for 11 ms duration (IEC 60068-2-27)
Regulatory Compliance	CE Marked, complies with relevant EU directives and standards for industrial equipment
Warranty Information	1-year limited warranty from date of purchase against manufacturing defects under normal use conditions

System Integration and Compatibility

The Omron NS8-TV00B-V2 programmable terminal is designed for seamless integration with Omron's comprehensive industrial automation ecosystem, including SYSMAC PLCs, NJ/NX-series controllers, and E5CC temperature controllers. The terminal supports standard industrial protocols for broad compatibility with third-party control systems. Its development environment allows for creation of customized operator interfaces with alarm management, data logging, and real-time monitoring capabilities. The Ethernet interface enables network connectivity for remote monitoring and integration with plant-wide automation systems.

Installation and Mounting Considerations

The NS8-TV00B-V2 features a panel-mount design with front IP65 protection when properly installed. The unit requires a panel thickness between 1.6 mm and 5 mm for secure mounting. For optimal performance, install the terminal in locations avoiding direct sunlight, excessive heat sources, or areas with conductive dust. Maintain adequate clearance around ventilation openings and consider ambient temperature conditions when selecting the installation location. The display viewing angle of ±80° horizontal and vertical ensures visibility from various operator positions.
