Omron NS8-TV01-V2 Programmable Terminal - Industrial HMI Solution

Premium Industrial HMI for Advanced Automation Control

The Omron NS8-TV01-V2 represents the pinnacle of industrial human-machine interface (HMI) technology, offering superior performance for mission-critical automation applications. As part of Omron's industry-leading NS Series programmable terminals, this advanced 8.4-inch touchscreen interface delivers unparalleled reliability in harsh industrial environments. Engineered with precision in Japan, the NS8-TV01-V2 combines robust construction with cutting-edge visualization capabilities, making it the ideal choice for factory automation, process control, and machine monitoring applications where operational excellence is non-negotiable.

Unmatched Features for Industrial Automation

• High-Resolution Industrial Display: 8.4-inch TFT color LCD with 800 × 600 SVGA resolution and 16-bit color depth provides crystal-clear visualization of complex process data and alarm conditions.
• Military-Grade Touch Interface: High-sensitivity resistive touchscreen ensures reliable operation even when wearing gloves or in wet conditions, with a 1 million-touch lifespan rating.
• Industrial-Grade Processing Power: 400 MHz RISC-based CPU with dedicated graphics accelerator handles multiple simultaneous processes without lag or screen refresh delays.
• Expanded Memory Architecture: 128 MB Flash ROM for program storage plus 64 MB SDRAM for runtime operations supports complex HMI applications with extensive historical data logging.
• Comprehensive Connectivity Suite: Dual USB 2.0 ports (1× Host Type-A, 1× Slave Type-B), RS-232C (D-Sub 9-pin), and RS-422/485 (terminal block) enable seamless integration with PLCs, sensors, and industrial networks.
• Extreme Environmental Durability: IP65-rated front panel protection against dust ingress and water jets, with NEMA 4X equivalent protection when properly panel-mounted.
• Wide Temperature Operation: Certified for continuous operation from 0 to 50°C (32 to 122°F) with 10-90% non-condensing humidity tolerance.
• Optimized Industrial Form Factor: Compact 249 × 194 × 60 mm (9.8 × 7.6 × 2.4 in) dimensions with 1.5 kg weight simplifies installation in control panels and machinery.
• Reliability Assurance: Backed by Omron's standard 1-year manufacturer warranty against defects in materials and workmanship.

Industrial Applications for Maximum Productivity

• Real-time monitoring and control of automated production lines in manufacturing facilities
• Centralized machine operation interfaces for CNC equipment and robotic workcells
• Process visualization and data acquisition in food & beverage, pharmaceutical, and chemical processing
• Quality control stations with statistical process control (SPC) chart displays
• Packaging machinery interfaces with barcode scanning integration capabilities
• Energy management systems for monitoring power consumption and equipment efficiency
• Wastewater treatment plant control and alarm monitoring stations
• Automotive assembly line production counters and andon systems

Comprehensive Technical Specifications

Specification Category	Detailed Parameters
Product Identification	Omron NS Series Programmable Terminal, Model NS8-TV01-V2
Display Technology	8.4-inch diagonal TFT active matrix LCD with LED backlight, 800 × 600 pixel resolution (SVGA), 16-bit color (65,536 colors), 300 cd/m² brightness, 500:1 contrast ratio
Touchscreen Specifications	4-wire resistive analog touch, 4096 × 4096 resolution, 1 million operations minimum lifespan, supports simultaneous two-point touch detection
Processing Architecture	RISC-based 32-bit processor @ 400 MHz with dedicated 2D graphics accelerator, real-time clock with battery backup
Memory Configuration	128 MB NAND Flash ROM (user program storage), 64 MB DDR SDRAM (operational memory), 2 MB FRAM for data retention
Communication Interfaces	USB 2.0 Host port (Type A connector): Supports USB memory sticks for data logging and program transfer USB 2.0 Slave port (Type B connector): For PC connection and programming RS-232C serial port (D-Sub 9-pin male): 115.2 kbps maximum, hardware handshaking support RS-422/485 serial port (terminal block): Configurable for 2-wire/4-wire operation, 115.2 kbps maximum
Electrical Characteristics	24 VDC nominal input (±10% tolerance), 1.5A maximum current draw, reverse polarity protection, 36W typical power consumption
Physical Dimensions	249 mm (9.8 in) width × 194 mm (7.6 in) height × 60 mm (2.4 in) depth (excluding mounting fixtures)
Weight and Mounting	1.5 kg (3.3 lbs) net weight, designed for panel mounting with IP65 protection when properly installed
Environmental Specifications	Operating Temperature: 0 to 50°C (32 to 122°F) with derating above 40°C Storage Temperature: -20 to 60°C (-4 to 140°F) Relative Humidity: 10% to 90% RH (non-condensing) Vibration Resistance: 4.9 m/s² (0.5G) at 10-55 Hz in X/Y/Z axes Shock Resistance: 147 m/s² (15G) for 11 ms duration
Protection Standards	Front panel IP65 (dust tight and protected against water jets), NEMA 4X equivalent when properly panel-mounted
Regulatory Compliance	CE Marked (EMC Directive, Low Voltage Directive), UL/cUL Listed (UL508), FCC Part 15 Subpart B Class A, RoHS compliant
Product Warranty	1-year limited warranty from date of purchase against defects in materials and workmanship under normal use

Seamless System Integration Capabilities

The Omron NS8-TV01-V2 programmable terminal is designed for effortless integration with Omron's complete industrial automation ecosystem, including NJ/NX-series PLCs, E5CC temperature controllers, and NX-IO safety components. Its native support for Omron's proprietary protocols (Host Link, FINS) ensures plug-and-play compatibility with existing Omron control systems, while standard communication interfaces allow connection to third-party equipment. The terminal's 128 MB Flash ROM capacity accommodates extensive screen development with multiple language support, making it suitable for global manufacturing operations. With its IP65-rated front panel and industrial-grade components, the NS8-TV01-V2 delivers reliable performance in the most demanding factory environments, from automotive plants to food processing facilities.
