NS8-TV01B-V2 Programmable Terminal with Touchscreen and V2 Enhanced Features
NS8-TV01B-V2 Programmable Terminal with Touchscreen and V2 Enhanced Features
SKU:NS8-TV01B-V2
Package size: 35X25X10CMOmron NS8-TV01B-V2 Programmable Terminal - Industrial HMI Solution
Premium Industrial Human-Machine Interface for Automation Control
The Omron NS8-TV01B-V2 represents the pinnacle of industrial human-machine interface technology from Omron's acclaimed NS Series. This professional-grade programmable terminal delivers superior performance for mission-critical automation applications across diverse industrial sectors. Engineered with precision and durability in mind, this advanced HMI solution provides operators with unparalleled control capabilities, real-time process visualization, and seamless integration with industrial control systems. The NS8-TV01B-V2 combines rugged industrial construction with sophisticated functionality, making it the ideal choice for demanding factory automation, process control, and machine interface applications where reliability and precision are paramount.
Advanced Technical Features
- High-Resolution Industrial Display: 8.4-inch TFT color LCD with 800 × 600 SVGA resolution and LED backlight technology ensures exceptional visibility with wide viewing angles, even in challenging industrial lighting conditions including direct sunlight or low-light environments.
- Industrial-Grade Touch Interface: High-sensitivity 4-wire resistive touchscreen provides reliable operation with precise input recognition, supporting both bare-hand and gloved-hand operation (compatible with most industrial gloves).
- Comprehensive Industrial Connectivity: Dual USB 2.0 ports (Type A host port for peripheral connection and Type B device port for programming), 10/100BASE-T Ethernet with RJ45 connector for high-speed network integration, and versatile RS-232C/RS-422/RS-485 serial communication options for flexible device connectivity.
- Rugged Industrial Design: Compact 225 × 178 × 60 mm (W×H×D) form factor with IP65-rated front panel protection against dust ingress and water jets, ensuring reliable operation in harsh industrial environments.
- Robust Power System: Wide-range 24 VDC (±10%) power input with low 24W power consumption and built-in protection against voltage fluctuations common in industrial settings.
- Extended Environmental Tolerance: Operational temperature range of 0°C to 50°C (32°F to 122°F) with storage capability from -20°C to 60°C (-4°F to 140°F), designed for continuous operation in demanding conditions.
- Mechanical Durability: Vibration resistance compliant with IEC 61131-2 standards (10-25Hz, 1.0mm amplitude) and shock resistance of 147 m/s² (15G) for 11ms in all directions, ensuring reliable performance in high-vibration industrial environments.
- Manufacturer Warranty: Backed by Omron's standard 1-year manufacturer warranty from date of purchase for quality assurance.
Industrial Applications and Use Cases
- Advanced Factory Automation: Comprehensive monitoring and control solution for modern production lines, robotic assembly systems, and automated material handling applications in automotive, electronics, and discrete manufacturing facilities.
- Precision Process Control: Ideal interface for critical process industries including chemical processing, pharmaceutical manufacturing, food and beverage production, and water treatment plants requiring precise parameter monitoring and adjustment.
- Industrial Machinery Interfaces: Primary operator interface for CNC machines, injection molding equipment, metal forming machines, and other industrial equipment requiring intuitive control and status visualization.
- Building Automation Systems: Effective solution for large-scale HVAC control, energy management systems, and integrated facility automation in commercial and industrial buildings.
- Packaging and Logistics Automation: Provides intuitive control for high-speed packaging machinery, filling systems, labeling equipment, and automated warehouse systems.
- Test and Measurement Systems: Suitable interface for industrial test benches, quality control stations, and production monitoring applications.
Detailed Technical Specifications
| Parameter | Detailed Specification |
|---|---|
| Model Number | NS8-TV01B-V2 (Omron genuine part number) |
| Display Technology | 8.4-inch TFT active matrix color LCD with white LED backlight, 16.7 million colors |
| Display Resolution | 800 × 600 pixels (SVGA standard) with 170° horizontal/vertical viewing angles |
| Touch Panel Type | Analog resistive (4-wire) with 4096 × 4096 resolution, 1 million touch cycles durability |
| USB Interfaces | 1 × USB 2.0 Type A (host) for peripheral connection, 1 × USB 2.0 Type B (device) for programming, both compliant with USB 2.0 Full-Speed (12Mbps) specification |
| Ethernet Communication | 10/100BASE-T (RJ45 connector) with auto-negotiation and auto-MDI/MDIX functionality |
| Serial Communication | RS-232C (D-Sub 9-pin male), RS-422/RS-485 (terminal block), configurable through software settings |
| Physical Dimensions (W×H×D) | 225 × 178 × 60 mm (8.86 × 7.01 × 2.36 inches) excluding mounting fixtures |
| Weight | 1.5 kg (3.31 lbs) net weight, suitable for panel mounting |
| Power Requirements | 24 VDC (±10%), 1.0A typical current consumption (24W), with reverse polarity protection |
| Operating Temperature Range | 0°C to 50°C (32°F to 122°F) with 20-90% RH (non-condensing) |
| Storage Temperature Range | -20°C to 60°C (-4°F to 140°F) with 20-90% RH (non-condensing) |
| Ingress Protection | IP65 (front panel only) per IEC 60529, NEMA 4X equivalent for dust and water jet protection |
| Vibration Resistance | 10-25Hz, 1.0mm amplitude (IEC 61131-2 compliant) for 2 hours in X/Y/Z directions |
| Shock Resistance | 147 m/s² (15G) for 11ms in X/Y/Z directions (IEC 60068-2-27 compliant) |
| Warranty Period | 1 year limited manufacturer warranty from date of purchase |
The Omron NS8-TV01B-V2 programmable terminal stands as a testament to Omron's commitment to industrial automation excellence. This professional-grade HMI solution delivers unmatched reliability, precision control, and intuitive operation for the most demanding industrial environments. With its robust construction, advanced connectivity options, and high-visibility display, the NS8-TV01B-V2 provides operators with the tools needed to maximize productivity while ensuring seamless integration with modern industrial control systems. Backed by Omron's 1-year manufacturer warranty, this programmable terminal represents a smart investment for businesses seeking to enhance their automation capabilities with a proven, industrial-strength interface solution.
