Compact E3Z-R61 2M Photoelectric Sensor with 2m Cable for Precise Detection
Compact E3Z-R61 2M Photoelectric Sensor with 2m Cable for Precise Detection
SKU:E3Z-R61 2M
Package size: 16X13X5CMRegular price
$18.00 USD
Regular price
Sale price
$18.00 USD
Unit price
/
per
Exclusive pricing & tailored solutions await!
Product Overview
The E3Z-R61 2M is a photoelectric sensor designed for reliable object detection. It belongs to the E3Z series, which is known for high-performance sensing in industrial environments. This model features a built-in amplifier and provides stable detection through a red LED light source.
Key Features
- Detection Method: Through-beam
- Light Source: Red LED (650 nm)
- Power Supply Voltage: 12-24 VDC ±10%
- Current Consumption: 15 mA max.
- Output Configuration: NPN or PNP (selectable)
- Response Time: 1 ms max.
- Operating Temperature: -25°C to 55°C
- Protection Rating: IP67
- Cable Length: 2 meters
- Dimensions: 18 mm (W) × 34 mm (H) × 50 mm (D)
Applications
- Conveyor belt object detection
- Packaging machine part presence verification
- Automated assembly line positioning
- Material handling systems
Technical Specifications
| Parameter | Value |
|---|---|
| Model | E3Z-R61 2M |
| Detection Method | Through-beam |
| Light Source | Red LED (650 nm) |
| Power Supply | 12-24 VDC ±10% |
| Current Consumption | 15 mA max. |
| Output Type | NPN/PNP (selectable) |
| Response Time | 1 ms max. |
| Operating Temperature | -25°C to 55°C |
| Protection Rating | IP67 |
| Cable Length | 2 meters |
| Dimensions (W × H × D) | 18 mm × 34 mm × 50 mm |
